Hydraulic load-sensing pump for mounting on the main or auxiliary engine.

Specifications

Capacity: 75 cc

Rotation: Anti-clockwise (HT1022SD), clockwise (HT1023SD) viewed from end of shaft

Connection: SAE-C flange, 14 spline shaft Side connection for suction and pressure Fits Twindisc gearboxes

Maximum r.p.m.: 2.880

Approx Weight: 27kg

Torque in Newton, Metres for each bar of operating pressure *: 1.2

Note:
* It may be necessary to reduce pump pressure to avoid exceeding the maximum allowed torque for the PTO, even if that means reduced power for the user device.
Non-standard pumps are made to order.
